IoT implementation sails into windpower

North Sea wind farms are fighting some striking battles, and they aren’t about sealife. They began with the breakdown of Germany’s biggest turbine bearing structures after 15 weeks; predictive maintenance had planned for the structure to last 15 months. The result was a disastrous maintenance bill and a reengineering of the giant blades that appear to be the culprit: they literally shook the turbine to death, says Joseph Zulick of MRO Electric and Supply.

A North Sea structure lost its main turbine housing this year, prompting engineers to determine that all 206 units of this size in the sea might need to be examined and refitted. The North Sea is the most violent wind and current area to have giant turbine farms in trouble, but other regions are having maintenance problems as well. (Also see)

The role of predictive maintenance in design engineering for these giants jumps up the importance ladder every time a customer adds megawatts to the overall farm scheme. Monitoring wind shear, temperature in the sea/air, wind speed, torque and vibration are now just the tip of the iceberg. Every design must include instant and early warnings about bearing temperature, housing integrity and wiring, above and below the waterline.

Build it in

In an article (1) about better connected maintenance, the author explains the importance of redundant systems in industrial networks connected to the most remote structures, like North Sea turbines. Every designer needs to combine early warning, security and responses like shutouts/shutoffs in new turbine designs. Maintenance strategies have always been designed as routines. These routines need severe upgrading, but the more aggressive approach is to add an active warning apparatus.

The best systems now combine the ability to optimise performance and better predict maintenance needs. The system is fast and powerful. “The platform’s unique ability to analyse terabytes of data with sub-second response times further improves our ability to generate significant value from our IoT applications,” the article said. Every wind turbine in operation under this study has more than 150 sensors checking speed, weather, vibration and acceleration (deceleration).

Another example of premium capability is a system designed for extreme weather vulnerability that not only analyses forecast data instantly but begins a failsafe operation before an emergency hits. IoT designers pursuing the most reliable information transfer must realise that severe weather can knock out various communication systems; sometimes, a hard-wired connection is the only way. In this case, a robust cable-based connection running along the main transmission cable could override Wi-Fi and satellite.

As a failsafe, this emergency plan could reduce or eliminate miscommunication between machines like shutoffs and reducers. This could also stop damage to machinery that is vulnerable to severely changing winds.

Intelligent software

The network for extreme environments must work in both directions. It must transmit from the sensor or probe out through protected mainframe, to the emergency board location. The resulting decision about a shutdown must be transmitted back through the same or another network. As is the result for severe weather changes, the response to overheating or breakage could be a shutdown or slowdown.

Joseph Zulick

In each incident, the more data that can be collected, the better the network can “learn” how and how not to proceed. Machine learning that starts with the safety of the equipment as top priority will adjust to circumstances.

Wind farms are an excellent example of connected machines that can operate independently until something goes wrong. Systems in machine learning can help refine operators’ choices, eliminating the need to shut the system down completely, or even shut a single turbine down.When the learning aspects of a network combine with more robust, redundant systems, they work together, making learning quicker and more efficient.

One example is the development by Siemens (2) development of SIMATIC computing, which the company calls “the core component of Totally Integrated Automation.” This technology moves the turbine farm closer to automatic production and, more importantly, toward self-regulation for safety purposes.

Size doesn’t matter

The lessons learned from tracking and troubleshooting systemslocated hundreds of miles out in an angry sea will help when designing safety into smaller turbine farms, on the scale of city or community electric grids. Most utilities have plans for wind and solar but are still concerned about costs, safety and support.

Designs for the next generation of turbines will be scalable, just as the farm is scalable today. Inside a single turbine system will be the ability to use machine learning and IoT to scale itself to its most efficient use, including shutting itself down or automatically sending its power to a battery site.

There are many examples of companies now designing for the future. Countries that seemed less concerned about wind and solar development a few years ago are now investing heavily. An example is Turkey, which has garnered $12 billion (€10.28 billion) in investment in wind over the last 11 years. (3) The country’s generated output in 2007 was 146 megawatts; last year, the wind power farms generated 6,500 megawatts, the report said. In an industry that multiplied out 50 times in 11 years, maintenance and better monitoring will be essential.

Turkey is far from alone growing wind power by factors of ten. The interconnected world runs on energy; the energy of the future will be interconnected, too. Wind can be a very big part of that picture if the hardware makers can guarantee its wireless electronic instrument needs are met, too.

The author of this blog is Joseph Zulick writer and manager at MRO Electric and Supply
